The SP7 Development Board equipped with the best-in-class performance-per-watt Spartan™ 7 FPGA, is built for designs requiring sensor fusion such as industrial networking, embedded vision, and automotive applications.

  The Board features high I/O availability and I/O expansion capability 40 Pin connector, making it the largest IP development for Spartan 7 FPGA users.

  With 23K logic cells and 150 I/O pins, the XC7S25 pairs expandable connectivity with high processing capability, all in a form factor ideal for edge applications.

  With the RS-422 Interface it will generates all the required control signals and monitors the input Signals.

Length : 164 mm

Height :  132.5 mm

Thickness(+/-5%): 1.6mm

Operating Environmental Temperature : -45°c to +85°c

Configuration

JTAG      :      Yes

QSPI       :     Yes

UART      :    Yes

Memory

Quad-SPI Flash:   256Mb

EEPROM:

Communication

UART :  1

Control & IO

Programmable IO Lines:  30

Expansion Connectors

40 Pin Connector:  1

Clocking

Standard Clock Oscillator:  Yes

Power

+5V Regulator:   Yes

RESOURCES

Programmable Logic Cells:  23K

Block RAM: 1,620 Kb

DSP Slices: 3,650

Maximum IO Pins: 150
